MAX UFO LED Bay Light - 23000 Lumens - 150W - 40K/50K Selectable - 3 Wattage Selectable

Product Search Code: 10-0121
KonliteSKU: RKRH0302LMWMCDNLCB
$119.99 $94.95

    • Replaces 250-400W Metal Halide
    • 0-10V Dimmable  (Dimmer NOT included, Separate Wiring Required)
    • 8Ft Power Cord with a Plug
    • Plug-N-Play Occupancy Sensor with Rotating Switch
    • Certificates: UL, DLC Premium 5.1
    • 5 Years Warranty
    • 5000K or 4000K Selectable
    • Watts and Lumens Selectable:
      • 150w = 23,200 (Preset)
      • 120w = 19,200
      • 100w = 16,200

    • Replaces 250-400W Metal Halide
    • 0-10V Dimmable  (Dimmer NOT included, Separate Wiring Required)
    • 8Ft Power Cord with a Plug
    • Plug-N-Play Occupancy Sensor with Rotating Switch
    • Certificates: UL, DLC Premium 5.1
    • 5 Years Warranty
    • 5000K or 4000K Selectable
    • Watts and Lumens Selectable:
      • 150w = 23,200 (Preset)
      • 120w = 19,200
      • 100w = 16,200

This high-performance Konlite RH03 MAX series LED Bay light is ideal for new construction or replacement of 250w to 400w HID/HPS. Delivers top energy savings and maintenance free durability for a wide range of applications.

  • Offers 3 Field Selectable Wattage/Brightness Settings and 2 Color Temperature tunable.
  • Designed for quick, easy installation-Each unit comes with 8' quick connect cord and plug.
  • Advanced aluminum heat sink for enhanced air flow, lower operating temperature and top efficiency.
show more
$119.99 $94.95


  • Secured payment methods. Revolve LED never stores nor has access to your card information.
  • 90 days return without restocking fee*.
  • $199 Free Shipping*$199 Free Shipping on eligible products*
  • Availability: Usually Ships in one to three business daysAvailability: Usually Ships in one to three business days.

This high-performance Konlite RH03 MAX series LED Bay light is ideal for new construction or replacement of 250w to 400w HID/HPS. Delivers top energy savings and maintenance free durability for a wide range of applications.

  • Offers 3 Field Selectable Wattage/Brightness Settings and 2 Color Temperature tunable.
  • Designed for quick, easy installation-Each unit comes with 8' quick connect cord and plug.
  • Advanced aluminum heat sink for enhanced air flow, lower operating temperature and top efficiency.
What's in the box
1 Lighting fixture - 1 Mount Hook - 1 Installation Guide
Product Details
Downloads
Reviews
Reviews
Q&A
1 Lighting fixture - 1 Mount Hook - 1 Installation Guide

Product Overview

Upgrade your space and reduce operating costs with the energy efficient Konlite RH03 MAX series round LED bay lights. This compact design is easy to install, meets any budget and a Contractor favorite for retrofit or new construction.

Selectable wattage and color temperature take the risk out of purchasing. A low/high bay light that is too dim or too bright can affect the daily operations of the space- from employee productivity to safety. You can now select your brightness and efficiency during install to assure the brightness meets the application and provides the amount of light you want and need for your area. Great for multi-zone facilities.

Three Field Selectable brightness Settings:

100w / 16,200 Lm, 120w / 19,200 Lm, 150w / 23,500 Lm   Preset at: 150 watts.

5000K and 4000K CCT selectable, Excellent color rendition compared to HID/HPS with uniform 120° broad beam illumination.

120-277V, Built in 4K surge protector, 8’ Quick Connect Cord, 0-10V Dimming, IP65 rated; Corrosion proof aluminum coating, fully sealed for dust and moisture intrusion.

Certified Quality: DLC 5.1 Premium for eligible rebates, UL, 5 year warranty.

Increase savings with the optional integrated PIR motion sensor. Set and adjust the controls via Remote Control: Brightness, Sensitivity, Hold-time, Daylight Harvesting and Stand by dimming level. Requires (1) HD05R Remote

Delivers top energy savings and maintenance free durability for a wide range of applications.

See similar High-watt Highbay version.

Applications

•Warehouses •Workshops
•Convention Centers •Automotive Centers
•Storage Facilities •Distribution Centers
•Factories •Supermarkets
•Retail •Gymnasiums
Color Temperature Selectable 4,000k & 5,000k color temperature
Certifications
US company5 years warrantyUL listed0-10v dimmableDLC PremiumRoHS compliance IP65 rating

Specification

BrandKonliteMPNRKRH0302LMWMCDNLCB
WarrantyLimited 5 YearsUPC
Input Voltage120-277VBeam120°
Input Wattage100w/120w/150wEqual To250W-400W
Lumens15,000/18,000/22,000CRI>70
Efficacy150 LM/WAvailable CCT5000k/4000k
Rated Life>50,000 hrsPower Factor>0.88
THD≤20%IP RatingIP65
Dimmable0-10VControlsoptional PIR Motion Sensor
Operating Temperature-40F to 113FDiameter12.4"
CertificationsUL, Damp Locations, DLC PremiumWeight7 Lbs

Occupancy Sensor Specification

BrandHaisenMPNHD09VCR-PH
ControlOn/off / 1-10V DimmingSetting toolRotating Switch or Remote Control (HD05R)
Detection area25%/50%/75%/100% (R.C)Hold time

5s/1min/5min/10min (Rotating Switch)

5s/30s/1min/3min/5min/10min/20min/30min (R.C)

Stand-by period0s/10s/30s/1min/5min/10min/30min/+∞ (R.C)Stand-by dimming level

0%/10%/30%/50% (Rotating Switch)

10%/20%/30%/50% (R.C)

Input Range12VDCDaylight thresholdDisable / 11 settings from 2Lux to 400Lux (R.C)
Operating Voltage10.5-15V DCDetection rangeMax. 45.92ft
Mounting heightMax. 39.37 ftIP ratingIP65
Current<15mAWarranty3 Years

*Stand-By Period need to be set to 0s while using with dimmer switch.

Factory Default Setting: Detection area 100%/ Hold time 5s/ Daylight threshold Disable/Stand-by period 0s/Stand-by dimming level 10%. Use Remote Control (HD05R) to change the factory Default Setting.
