TYPE IV Vela LED Parking Lot Light - 310W - 4 Watts - 3 CCT - 277-480V - 46,600 LM - 1000W Equal

Product Search Code: 20-0420
KonliteSKU: KVLHMWMCHV4SF
$344.65

    • Type IV Lighting Distribution

    • Replaces 750-1000W Metal Halide Light
    • Price Includes One of the Mounting Brackets
    • Certificates: UL, DLC 5.1 Premium
    • 5 Years Warranty
    • Three CCT Field Selectable: 3000K, 4000K or 5000K (Preset)
    • Watts and Lumens Selectable:
      • 310w = 46,600 (Preset/5000K)
      • 280w = 42,100
      • 260w = 39,100
      • 240w = 34,900
    • 26 In. Pigtail

    • Type IV Lighting Distribution

    • Replaces 750-1000W Metal Halide Light
    • Price Includes One of the Mounting Brackets
    • Certificates: UL, DLC 5.1 Premium
    • 5 Years Warranty
    • Three CCT Field Selectable: 3000K, 4000K or 5000K (Preset)
    • Watts and Lumens Selectable:
      • 310w = 46,600 (Preset/5000K)
      • 280w = 42,100
      • 260w = 39,100
      • 240w = 34,900
    • 26 In. Pigtail

The Konlite Vela LED Parking Lot light delivers superior illumination, energy saving and easy installation.  Sleek and modern low profile design combined with rugged construction make the Vela series a top choice for Parking lots, Pole lights, Campuses, Public Parks, Building Areas, Arenas and Roadways.

  • High luminaire efficacy, up to 160lm/W at maximum output
  • Designed for easy one person installation
  • 277-480V,100,000 hour lifespan. 5 year warranty
show more
$344.65


  • Secured payment methods. Revolve LED never stores nor has access to your card information.
  • 90 days return without restocking fee*.
  • $199 Free Shipping*$199 Free Shipping on eligible products*
  • Availability: Usually Ships in one to three business daysAvailability: Usually Ships in one to three business days.

The Konlite Vela LED Parking Lot light delivers superior illumination, energy saving and easy installation.  Sleek and modern low profile design combined with rugged construction make the Vela series a top choice for Parking lots, Pole lights, Campuses, Public Parks, Building Areas, Arenas and Roadways.

  • High luminaire efficacy, up to 160lm/W at maximum output
  • Designed for easy one person installation
  • 277-480V,100,000 hour lifespan. 5 year warranty
What's in the box
1 Lighting Fixture - 1 Mounting Bracket with Screws - 1 Installation Guide
Product Details
Downloads
Reviews
Reviews
Q&A
1 Lighting Fixture - 1 Mounting Bracket with Screws - 1 Installation Guide

Konlite VELA Series LED Area Light

High Performance- Designed for easy installation- 5 Mounting Options

One of the most important safety considerations for night time lighting is visibility. Increase safety and security to your buildings and lots when LED lighting clears pathways, hazards and deters crime.

 Great for multi-zone facilities and helps eliminate back light waste. This LED Parking Lot light provides up to 65% energy savings, long service life and quick return of investment. You can now select your brightness and efficiency during installation to ensure the brightness meets the application and provides the amount of light you want and need for your area. With a 4-way switch, you can choose from four field-selectable wattage/brightness settings ( 310W/46,600 Lm preset, 280W/42,100 Lm, 260W/39,100 Lm, 240W/34,900 Lm), to meet your specific lighting needs.

The high output LEDs and custom optics provide excellent light distribution with 160 Lumens per Watt Efficiency. Type IV Beam Distribution, UV resistant polycarbonate optical lens.   CCT color 5000K, 4000K and 3000K selectable.

With IP65 Corrosion proof Die-cast aluminum housing and mounting brackets and built-in 10KV surge protection, it is built to withstand all weather elements, Bronze finish.  The sleek and modern aesthetics combined with rugged construction make the VELA area light ideal for one to one replacement of HID/HPS or new construction projects.

Low EPA, Lightweight design, 1.5G vibration load per ANSI C136.31.

Certified Quality: DLC 5.1 Premium for eligible rebates, UL, 100,000 hr. life span, 5 year warranty.

The Konlite VELA series LED Parking Lot Light can be mounted directly on round or square pole, wall or other surfaces.

Enhance your parking lot's efficiency and security with the Revolve LED Parking Lot PIR Motion Sensor. The motion sensor kits SKU is KVLH-HD09VR-PH. This cutting-edge sensor is designed to seamlessly integrate with your existing LED lighting setup, providing optimal motion detection to illuminate areas only when needed.

Mounting options: Extrusion Arm, Yoke, Slip-fitter, Wall-mount or Universal Bracket ( All-in-one Slip Fitter and Pole Mount Extrusion Arm ).

Applications

•Area Lighting •Parking Lots
•Streets

•Building Façade

•Storage Facilities •Underpasses & Tunnel
•Boat Docks & Marinas • Billboards
•Warehouses •Metal Buildings
•Roadways & Pathways •Security Lighting
•Sports Complex •Schools & Universities
•Parks •Car Dealerships
Color Temperature Selectable 3,000K, 4,000k & 5,000k color temperature
Certifications
5 years warranty

Specifications

BrandKonliteDLC Part #KVLHMWMCHV4[SF,TR,EX,UN,WM]
WarrantyLimited 5 YearsDLC PartnerKonlite
Input Voltage277-480VOpticalType IV
Input Wattage310W/280W/260W/240WEqual to1000W
Delivered Lumens46810 LumensCRI>70
Efficacy160 lm/WAvailable CCT5000K/4000K/3000K
Rated Life>100,000 hrsTHD<20%
Power Factor>0.9IP RatingIP65
DimmableN/AControls480V Photocell
Operating Temperature-40 °F to 113 °FDimensionsSee Specifications
CertificationsUL, Wet Locations, DLC PremiumWeight19.26 lbs

Konlite Vela LED Parking Lot Light Video

Video of Konlite Vela LED Parking Lot Light - 310W - 277-480V - 46,800
