ALTA LED High Bay Light - 4FT - 225W/195W/175W - 37,600 Lumens - 5000K/4000K Selectable - 120-277V - 600W Equal
- Replaces 400-600W Metal Halide
- 0-10V Dimmable
- CCT: 5000K or 4000K with CRI of 80
- Light Dimensions: 44.29"x12.6"x2.95"
- 5 Years Warranty
- Certificates: UL, DLC Premium 5.1, NLC
- Watts and Lumens Selectable:
- 225w = 36,650 (5000K, Preset)
- 195w = 32,400
- 175w = 29,940
- Replaces 400-600W Metal Halide
- 0-10V Dimmable
- CCT: 5000K or 4000K with CRI of 80
- Light Dimensions: 44.29"x12.6"x2.95"
- 5 Years Warranty
- Certificates: UL, DLC Premium 5.1, NLC
- Watts and Lumens Selectable:
- 225w = 36,650 (5000K, Preset)
- 195w = 32,400
- 175w = 29,940
This high-performance Konlite LED Linear High Bay Light Series is ideal for new construction or replacement of 1000W. Delivers top energy savings and maintenance free durability for a wide range of applications.
- Designed for quick, easy installation-Each unit comes with V Hook and hanging chain
- Secured payment methods. Revolve LED never stores nor has access to your card information.
- 90 days return without restocking fee*.
![$199 Free Shipping*]()
$199 Free Shipping on eligible products*![Availability: Usually Ships in one to three business days]()
Availability: Usually Ships in one to three business days.
Product Overview
This 4ft LED Linear high bay ceiling light is an ideal replacement for aging T8, T5, 400-600 watt HID retrofit or new construction general lighting applications. The high performance compact design allows for easy installation.
Multiple brightness and color options with the flip of a switch:
Wattage/Lumens ( 5000K Setting ) : 225W/36,650 195W/32,400 175W/29,940
Color CCT: 4000K Neutral White or 5000K Daylight White
Delivers top energy savings and maintenance free durability for a wide range of applications. Provides enhanced visibility and safety over traditional lighting.
Frosted polycarbonate diffuser creates even and glare free light distributed broadly at a 120° beam angle.
0-10V Dimming, Delivers top energy savings and maintenance free durability for a wide range of applications.
The light fixture comes with hanging chains.
Optional Plug-N-Play motion sensor with Rotating Switch has built-in daylight sensing capability. Upgrade your lighting control system with Haisen Blue Network Lighting Controls (NLC) and discover the ultimate in flexibility, affordability, and ease of use. Perfect for businesses and facilities of all sizes, the DLC qualified NLC system empowers you to take full command of your lighting environment, enhancing efficiency and ambiance with just a few simple clicks. Simply select NLC Bluetooth sensor with ALTA High Bay Lights, ensuring a smooth and efficient control experience right out of the box.
Cost effective and quality solution for: Excellent for aisle optics, Warehouses and storage, Industrial facilities, Retail centers, Auto Centers, Manufacturing, Sports facilities and Gymnasiums.
See similar 300-watt, 165-watt and 105-watt versions.
Applications
| •Warehouses | •Workshops |
| •Convention Centers |
•High Bays |
| •Storage Facilities | •Distribution Centers |
| •Factories | •Supermarkets |
| •Retail | •Gymnasiums |
Specification
| Brand | Konlite | MPN | KAT225MCLV4F |
| Warranty | Limited 5 Years | UPC | 659359627132 |
| Input Voltage | 120-277V | Beam | 120° |
| Input Wattage | 225W/195W/175W | Equal To | 400-600W or 6 lamp T8/T5 |
| Delivered Lumens | 36,650/32,400/29,400 (5000K) 37,600/33,200/30,100 (4000K) | CRI | 80 |
| Efficacy | 160-170 LM/W | Available CCT | 5000K/4000K |
| Rated Life | >50,000 hrs | Power Factor | 0.9 |
| THD | 15% | IP Rating | IP20 |
| Dimmable | 0-10V(Dimmer NOT included, Separate Wiring Required) | Mounting | Chain, Surface, Pendant |
| Operating Temperature | -40F to 113F | Dimensions | 44.29”X12.6”X2.95" |
| Certifications | UL, Damp Locations, DLC Premium, NLC |
Motion Sensor Specification
| Brand | Haisen | MPN | HD09VR-PH/HD09VR-PHB(Blue Tooth) |
| Control | On/off / 1-10V Dimming | Setting tool | Rotating Switch or Remote Control (HD05R). For Network Lighting Controls (NLC), controlled with “Haisen Blue” APP at iOS or Android smartphones |
| Detection area | 25%/50%/75%/100% | Hold time | 5s/30s/1min/3min/5min/10min/20min/30min |
| Stand-by period | 0s/10s/30s/1m/5m/10m/30m/60m/+∞ | Stand-by dimming level | 10%/20%/30%/50% |
| Motion detection | 0.5~1.5m/s | Daylight threshold | Disable / 8 settings from 2Lux to 400Lux |
| Mounting height | Max. 39ft | Detection range | Max. 45ft |
| Operating Voltage | 10-15V DC | IP rating | IP65 |
| Current | <15mA | Warranty | 3 Years |
*Stand-By Period need to be set to 0s while using with dimmer switch.
*Factory Default Setting: Detection area 100%/ Hold time 5s/ Daylight threshold Disable/Stand-by period 0s/Stand-by dimming level 10%. Use Remote Control (HD05R) to change the factory Default Setting.
