ALTA LED Low Bay Light - 2FT - 105W/90W/80W - 16,500 Lumens - 5000K/4000K Selectable - 120-277V - 250W Equal

Product Search Code: 10-0127
KonliteSKU: KAT105MCLV2F
$109.99 $89.65

    • Replaces 150-250W Metal Halide
    • 0-10V Dimmable
    • CCT: 5000K or 4000K with CRI of 80
    • Light Dimensions: 23.23"x12.6"x2.95"
    • 5 Years Warranty
    • Certificates: UL, DLC Premium 5.1, NLC
    • Watts and Lumens Selectable:
      • 105w = 16,100 (5000K, Preset)
      • 90w = 14,100
      • 80w = 12,800

    • Replaces 150-250W Metal Halide
    • 0-10V Dimmable
    • CCT: 5000K or 4000K with CRI of 80
    • Light Dimensions: 23.23"x12.6"x2.95"
    • 5 Years Warranty
    • Certificates: UL, DLC Premium 5.1, NLC
    • Watts and Lumens Selectable:
      • 105w = 16,100 (5000K, Preset)
      • 90w = 14,100
      • 80w = 12,800

This high-performance Konlite LED Linear Low Bay Light Series is ideal for new construction or replacement of 250W. Delivers top energy savings and maintenance free durability for a wide range of applications.

  • Designed for quick, easy installation-Each unit comes with V Hook and hanging chain
  • Assembly made of heavy duty gauge steel, rigidly designed to resist twisting and bowing
  • Optional motion sensor with daylight sensing function to maximize power savings
  • DLC Premium and DLC certified qualifying for maximum rebates where applicable
show more
$109.99 $89.65


  • Secured payment methods. Revolve LED never stores nor has access to your card information.
  • 90 days return without restocking fee*.
  • $199 Free Shipping*$199 Free Shipping on eligible products*
  • Availability: Usually Ships in one to three business daysAvailability: Usually Ships in one to three business days.

This high-performance Konlite LED Linear Low Bay Light Series is ideal for new construction or replacement of 250W. Delivers top energy savings and maintenance free durability for a wide range of applications.

  • Designed for quick, easy installation-Each unit comes with V Hook and hanging chain
  • Assembly made of heavy duty gauge steel, rigidly designed to resist twisting and bowing
  • Optional motion sensor with daylight sensing function to maximize power savings
  • DLC Premium and DLC certified qualifying for maximum rebates where applicable
What's in the box
1 Lighting Fixture - 2 Set Chain -1 Installation Guide
Product Details
Downloads
Reviews
Reviews
Q&A
1 Lighting Fixture - 2 Set Chain -1 Installation Guide

Product Overview

This 2ft LED Linear Low bay ceiling light is an ideal replacement for aging T8, T5, 250 watt HID retrofit or new construction general lighting applications. The high performance compact design allows for easy installation.

Multiple brightness and color options with the flip of a switch:

Wattage/Lumens ( 5000K Setting ) : 105W/16,100  90W/14,100  80W/12,800

Color CCT: 4000K Neutral White or 5000K Daylight White

Delivers top energy savings and maintenance free durability for a wide range of applications. Provides enhanced visibility and safety over traditional lighting.

Frosted polycarbonate diffuser creates even and glare free light distributed broadly at a 120° beam angle.

0-10V Dimming, Delivers top energy savings and maintenance free durability for a wide range of applications.

The light fixture comes with hanging chains.

Optional Plug-N-Play motion sensor with Rotating Switch has built-in daylight sensing capability. Upgrade your lighting control system with Haisen Blue Network Lighting Controls (NLC) and discover the ultimate in flexibility, affordability, and ease of use. Perfect for businesses and facilities of all sizes, the DLC qualified NLC system empowers you to take full command of your lighting environment, enhancing efficiency and ambiance with just a few simple clicks. Simply select NLC Bluetooth sensor with ALTA High Bay Lights, ensuring a smooth and efficient control experience right out of the box.

Cost effective and quality solution for: Excellent for aisle optics, Warehouses and storage, Industrial facilities, Retail centers, Auto Centers, Manufacturing, Sports facilities and Gymnasiums.

See similar 300-watt, 225-watt and 165-watt versions.

Applications

Warehouses •Workshops
•Convention Centers

•High Bays

•Storage Facilities •Distribution Centers
•Factories •Supermarkets
•Retail •Gymnasiums
Color Temperature Selectable 4,000k & 5,000k color temperature
Certifications
US company5 years warrantyUL listed1-10V dimmableDLC PremiumRoHS compliance FCC certification

Specification

BrandKonliteMPNKAT105MCLV2F
WarrantyLimited 5 YearsUPC659359813443
Input Voltage120-277VBeam120°
Input Wattage105W/90W/80WEqual To250W or 2-4 lamp T8/T5
Delivered Lumens

16,100/14,100/12,800 (5000K)

16,500/14,450/13,100 (4000K)

CRI80
Efficacy153-163 LM/WAvailable CCT5000K/4000K
Rated Life>50,000 hrsPower Factor0.9
THD15%IP RatingIP20
Dimmable0-10V(Dimmer NOT included, Separate Wiring Required)MountingChain, Surface, Pendant
Operating Temperature-40F to 113FDimensions23.23”X12.6”X2.95"
CertificationsUL, Damp Locations, DLC Premium, NLC

Motion Sensor Specification

BrandHaisenMPNHD09VR-PH/HD09VR-PHB(Blue Tooth)
ControlOn/off / 1-10V DimmingSetting tool

Rotating Switch or Remote Control (HD05R).

For Network Lighting Controls (NLC),  controlled

with “Haisen Blue” APP at iOS or Android

smartphones

Detection area25%/50%/75%/100%Hold time5s/30s/1min/3min/5min/10min/20min/30min
Stand-by period0s/10s/30s/1m/5m/10m/30m/60m/+∞Stand-by dimming level10%/20%/30%/50%
Motion detection0.5~1.5m/sDaylight thresholdDisable / 8 settings from 2Lux to 400Lux
Mounting heightMax. 39ftDetection rangeMax. 45ft
Operating Voltage10-15V DCIP ratingIP65
Current<15mAWarranty3 Years

*Stand-By Period need to be set to 0s while using with dimmer switch.

*Factory Default Setting: Detection area 100%/ Hold time 5s/ Daylight threshold Disable/Stand-by period 0s/Stand-by dimming level 10%. Use Remote Control (HD05R) to change the factory Default Setting.
